MYRON & DAVIS - KHDM7
7.0" TFT/LED Headrest Mount Monitor With Built-in DVD

FEATURES

  • 7" TFT-LED-screen with head restraint
  • Built-in DVD Player with support for DVD, VCD, AUDIO CD-R/RW and MP3 CD
  • Built-in Wireless Headphone IR Transmitter
  • 1 Audio/Video Input in each headset
  • Full function wireless remote control
  • OSD (On Screen Display). Graphic menu used to adjust picture quality, image, and clarity.
  • Integrated with the vehicles audio system (If applicable). Audio can be output through the vehicle's speakers using the factory AUX port.
  • Primary function controls integrated to front bezel.

SPECIFICATIONS

  • Display: 7.0" widescreen, TFT LED active matrix
  • Resolution: 800 (W) x 480 (H) x3 (R.G.B.)
  • Dot Pitch: 0.0635 (W) x 0.1905 (H)
  • Viewing Angle: 50/70/70/70 (from above/below/left/right)
  • Brightness: 450 cd/m
  • Contrast Ratio: 500:1
  • Power: 12V DC (negative ground)
  • Power Consumption: Active (DVD being played): approx. 20W, Max(start-up and insert of disc): approx. 32W
  • Panel Dimensions: 165 x 5.5 x 104mm (W x D x H)
  • Built-in Temperature Control System: If temperature is greater than +175F (+80C), system will power down.

Note: Temperature control system monitors the temperature of the circuit board inside the device and not the ambient temperature outside in the passenger compartment.



MYRON & DAVIS - ACCM85
8.5" TFT/LCD Headrest Mount

FEATURES

  • 8.5" Active Matrix Display
  • 16:9 Aspect Ratio Wide Screen
  • Fully Integrated Side Load DVD Player
  • Built-in IR Transmitter (Passenger: 2.3MHz/2.8MHz - Driver: 3.2MHz/3.8MHz)
  • Full Menu Control with OSD
  • Screen Pivots 30 to Improve Viewing Angle
  • USB Port Can Charge an iPod (with adapter) or Read MP3/AVI/JPEG/WMA files from a Jump Drive

SPECIFICATIONS

  • Resolution: 480 X 234
  • 1 AV Input (RCA)
  • Viewing Angle: Left/Right: 65, Up/Down 65/50
  • Brightness: 400 cd/m2
  • NTSC/PAL Auto Switching
  • Auto Shut Off Feature
  • Full Function Wireless Remote Control
  • Compatible Media: DVD/VCD/SVCD/CD/CD-R/DVD-R
  • Last Scene Memory
  • Zoom Feature
  • Slow Play Back
  • 4 Speed Scan
  • Step Play/Program Play
  • Multiple Language Menu/Subtitles
  • Fast Forward/Reverse

ACCM85L (driver side with DVD player)
ACCM85R (passenger side with DVD player)

Fits: *Mercedes 2009+ ML/GL/R Class, *BMW X3, X5, X6, 5 Series, 7 Series, *Audi Q7
